Public EV Charging Stations For Bus Depot in Hyderabad

Axonify offers the best electric vehicle charging solutions for bus depots. These solutions are specifically designed to meet the charging needs of large-scale public transportation, making it convenient and efficient for buses to charge and be ready for their routes.

One of the key advantages of Axonify’s EV charging solutions for bus depots is their convenience. With strategically placed charging stations within the depot, buses can easily access them during their downtime or between shifts. This ensures that the charging process does not disrupt the regular operations of the depot and allows for a seamless transition to electric buses.

This not only improves the overall efficiency and productivity of the bus fleet but also contributes to the reduction of emissions and promotes sustainable transportation.

Atom AC Destination Ev Charging

Atom: 232-2G40-2G40

Our Atom AC Destination Charger is the perfect solution for multiple vehicles charging in commercial spaces. It provides the users with a safe & fast charging experience and comes with a LCD Display and a Simple User Interface. The ergonomic design ensures a seamless experience for multiple users.

Capacity: 7.4 kW, 15 kW, 22 kW, 80 kW

Key Features

Our Atom AC charger is a smart EV charging solution for multiple vehicles charging in commercial spaces.
This charger can easily be used with a Smart Card Reader and App-based Payment gateway.

This charger comes with a Suitable Stand Mount And Wall Mount Option and a High-Quality Enclosure with IP54.
Bharath AC001, J1772, and Type2 AC charging.

Design

LCD Display, state-of-the-art Hardware and IP54 Outdoor enclosure.

Safety

Safety first, with various protection features built-in for Surge, Ground Fault, Short Circuit etc. Meets Indian & International Charging Standards.

Payment Gateway

Hassle-free authentication using RFID & Mobile App. Secure payment options including UPI, Debit/Credit cards.

Large Charging Simplified!

Our Atom AC Box charger is super easy-to-use and extremely user-friendly. It is based on the latest technology to support simultaneous multiple EV Charging in large and commercial spaces. The universal design ensures charging for all personal and commercial vehicles. This charger comes with a display and will fast charge your vehicles compared to other AC Chargers.

This product is thoughtfully designed to and tough use of by multiple users in large parking spaces, malls, bus depots, big offices, and more and comes with safe payment gateway options.

Bus Depot / Operators

Destination charging at bus depots and private bus operator hubs

Commercial

Hotels, Resorts, IT Parks & Office Buildings

Technical Specification

Product Information

Input/output power rating and current

Three-phase: Upto 80 kW / 126 A

Connector type

2 Gun: Type 2 IEC-62196 Female Plug,
with 5 m cable

Protection

Surge protection, Short circuit protection Overload protection, AC overvoltage protection, under-voltage protection, and Leakage protection.

Input/ouput voltage

Three-phase: 380 to 450 V nominal, 50 Hz

Energy metering

Class 1

User Interface

Connectivity

Ethernet, Option for 4G, Wifi

User authentification

Mobile App or RFID Card

Status indication

LED’s

User interface

LCD

Configuration

Control and configuration

OCPP 1.6J (Optional)

Payment gateway

Optional

User Interface

IP rating

IP54

Operating temperature range

-20 to 55 °C

Dimensions

W x H x D (400 x 1680 x 250 mm)

Storage temperature range

-30 to 70 °C

Mounting

Wall or floor using a pedestal

Certification And Standards

Codes and standards

IS 17017-1
AIS-138 Part1
IEC 61851-1
IEC 62196-2
